DawnRay DR400GW - 4" OCCT Round Gimbal Slim Panel - 9W - 100-125V AC - 0.09A - 700 Lumens - 38° Beam Angle - 3000K, 4000K, 5000K All in One - White Trim - Dimmable

DawnRay DR400GW - 4" OCCT Round Gimbal Slim Panel - 9W - 100-125V AC - 0.09A - 700 Lumens - 38° Beam Angle - 3000K, 4000K, 5000K All in One - White Trim - Dimmable
Click to enlarge
Price Per Item: $18.00
Availability: In Stock
Model: DR400GW
Manufacturer: OEM Manufacturer
Average Rating: Not Rated

DawnRay DR400GW - 4" OCCT Round Gimbal Slim Panel - 9W - 100-125V AC - 0.09A - 700 Lumens - 38° Beam Angle - 3000K, 4000K, 5000K All in One - White Trim - Dimmable

DR400GW/DR400GB/DR400GN

Body

• Durable airtight aluminum;
• Adjustable gimbal, maximum up to 25° tilting;

LED Characteristics

• 12-Watt LED module;
• Minimal heat emission.
• Up to 700 lumens, 82 CRI;
• Superior LED performance and lifespan;
• Excellent color rendering with spotlight;

Dimming

• 100% -10% dimming capability;
• Compatible with industry standard TRIAC/ELV dimmers (contact factory for listing of compatible dimmers);

Environment

• Suitable for damp locations;
• Suitable for insulated ceiling application;
• Can be installed indoor and for outdoor applications

Description

DR400GW, a 9 watt 4-inch OCCT (Switch-selectable color temperature in 3000K, 4000K, 5000K) slim prole round gimbal LED panel is a high-performance, easy to install downlight. It oers excellent light output, energy eciency and streamlined design. Adjustable gimbal is benecial to the adjustment of angle. Suitable for damp location and use in sots.

Beam Spread

• 38° beam spread;

Mounting

• Included two spring loaded clips to attach to any ceiling material;
• The slim prole allows to be mounted under joists or duct work;

LED Driver

• Extruded aluminum junction box with integrated 210mA dimmable driver included
• Class II electronic LED driver with 100 – 125V AC input;
• Includes an 18" cable from driver to xture;

Quick Connect Push-in Terminals

• Three “Quick Connect” push-in terminals for fast and easy wiring;

Operating Temperature

• -20°C~40°C (-4°F~104°F)

Brochures & Specific Sheets




Stock Code DR400GW
Brand DawnRay
Family OCCT Round Slim Panel
Voltage (V) 100-125V AC
Diameter (in) 4.72''
Bulb Type LED
Lumens (Initial) 700 Lumens
Color White
CRI 82
Color Temperature (K) 3000K, 4000K, 5000K All in One
Dimmable Yes
Case Quantity 1
Wattage (w) 9 Watts
Start Temp. (Max) 104°F (+40°C)
Start Temp. (Min) -4°F (-20°C)
Beam Angle 38 Degree
Power Factor >0.95
Mounting Ceiling Recess Mount
Warranty 5 Years Warranty
UL Listed cETLus
